Direct Current Adapter – Introducing the GIL‑75206‑24

A Rugged Power Solution for Rugged Environments
Amironic is proud to introduce the GIL‑75206‑24 military-grade DC adapter – compact, isolated, and built for battle.

In a world where every volt matters — especially under fire, inside a tactical vehicle, or under industrial load — stability, protection, and reliability aren’t optional; they’re mission-critical.
Military systems don’t forgive voltage drops, overheating, or EMI – not in the field, and not in the lab.
This is why the GIL‑75206‑24 is built to strict standards, with a focus on durability, noise filtering, and resilience in unpredictable environments — from battlefield to cockpit.

The GIL‑75206‑24 from GILGAL Power Engineering was designed for exactly this:
An isolated DC‑DC adapter, spike-resistant, vibration-hardened, and up to 90% efficient.
Amazingly compact — yet built like a tank.
Whether it’s for a field computer, communication unit, or weapon system — this adapter delivers clean, stable, protected 24V output — under any condition.

As the official distributor of GILGAL in Israel, Amironic provides local availability, native-language technical support, and the backing of a trusted Israeli manufacturer that understands the field.

⚡ How Clean Is the 24V Output, Really?
The following graph shows how the output voltage of the GIL‑75206‑24 remains stable and clean, even as the load gradually increases. Ripple is kept extremely low (30–70mV), far below standard thresholds, enabling direct use with sensitive equipment without fear of coupling or EMI interference

⚙️ Full Technical Overview

🔋 Electrical Specifications:

• Input Voltage Range: 10VDC to 36VDC — ideal for unstable sources (batteries, vehicle systems)

• Output Voltage: 24VDC, fully isolated

• Output Accuracy: ±1.5% (Line + Load Regulation)

• Max Power: 150W (6.25A)

• Efficiency: Typically 90% — reduced heat, higher performance

• Output Protection: Overcurrent protection via Hiccup Auto-Restart — self-recovers after fault

• Input Protection: Reverse polarity protection — with auto-recovery

✅ Military-Grade Compliance:

• MIL‑STD‑1275A/B: including ±250V spike and 100V surge immunity

• MIL‑STD‑704 A/B/C/D: for airborne systems

• MIL‑STD‑461F (CS101): input EMI filtering

---

🔌 Interface and Connectors:

• Connector Type: D-Type, 15-pin

• Manufacturer: TE Connectivity AMP 2334100‑2

• Mating Connector: AMP 2334099‑2

Enable Logic:

• GIL‑75206‑24: High Active (ON when open)

• GIL‑75206‑24n: Low Active (ON when shorted to GND)

Pin Assignment:

• Vin: Pins 1, 2, 9

• GND (Input): Pins 3, 4, 11

• GND (Output): Pins 5, 6, 12, 13

• Vout: Pins 7, 8, 14, 15

• Enable: Pin 10

---

🧱 Mechanical Data:

• Dimensions: 160×80×33 mm ±3 mm

• Weight: ~350 grams

• Mounting: 4 x 4/40 screws

• Thermal Note: Requires thermal pad between unit base and heat sink surface

---

🌡️ Environmental Endurance:

• Operating Temperature: −40°C to +72°C

• Storage Temperature: −40°C to +85°C

• Operating Altitude: up to 45,000 ft

• Vibration: per MIL‑STD‑810G (vehicles, helicopters, aircraft, loose cargo)

• Shock: 40g SRS shock, duration 15–23ms

---

🛡️ Competitive Advantage

---

💡 Use Cases:

• 24V-based portable systems: rugged laptops, mobile power stations, chargers

• Armored vehicles, radar, and air-defense systems

• Field command and control systems

• UAV and airborne electronics

• Mobile communications and logistics stations

---

🛒 Availability and Ordering

The GIL‑75206‑24 is available immediately via Amironic.
Custom variants available — including Low Active logic, wiring changes, or alternate output voltages.

---

🆕 Need More Power?
If you’re looking for an even tougher solution – meet the GIL8628C‑18, the big brother of the 75206.
This rugged DC-DC converter delivers up to 500W at 28V/18A, with DO‑160E aerospace compliance, IP67 waterproof rating, up to 94% efficiency, and baseplate cooling – all without compromising on full military-grade protections.

GIL8628C‑18 is built for heavy-duty missions:
⚙️ Broadcasting systems, mobile energy infrastructure, UAV ground stations, and military-grade communications – wherever true rugged DC power is required.
✔️ Available through Amironic, with Hebrew-language support and custom configurations upon request.
