In modern defense systems, stability equals accuracy.
Whether mounted on a remote weapon station, a turreted vehicle, or an autonomous surveillance platform, every vibration or degree of drift can make the difference between a hit and a miss.
The LandMark005 IMU by Gladiator Technologies delivers the precision and responsiveness needed to keep your system perfectly aligned, even under the harshest dynamic conditions.
🎯 Stabilizing the Fire – How It Works
At the heart of a turret stabilization or fire-control loop lies an Inertial Measurement Unit (IMU) that continuously senses motion.
The LandMark005 measures angular rate and linear acceleration on all three axes, detecting even micro-movements caused by terrain, recoil, or sudden maneuvers.
These readings are transmitted instantly to the control computer, which adjusts the servo motors in real time — keeping the barrel or camera line-of-sight locked on target while the vehicle is moving.
With a user-configurable bandwidth up to 1000 Hz (VELOX® Plus), the LandMark005 reacts within milliseconds, ensuring that stability and accuracy are maintained even in high-vibration environments.
⚙️ Technical Highlights
-
Bandwidth: Up to 1000 Hz with VELOX® Plus
-
Gyro ARW: 0.0018 °/s/√Hz
-
Bias Stability: 4 °/hr typical
-
Accel VRW: 0.05 mg/√Hz
-
Environmental: –50 °C to +85 °C operation, 1000 g shock, 8 g rms vibration
-
Data Rate: Up to 10 kHz with 7.5 MBaud RS-422/485 interface
LMRK005_TechnicalSummary
LMRK005_SX2_ExamplePerformanceD…
Each unit is factory-calibrated over temperature to ensure repeatable accuracy and long-term reliability.
🛡️ Compact. Rugged. Ready for the Field.
Weighing only 19 grams and measuring 25 × 25 × 15 mm, the LandMark005 integrates easily into compact stabilized payloads and embedded systems.
It’s built to meet MIL-STD-810 standards for vibration, shock, and temperature — making it ideal for defense, aerospace, and harsh industrial applications.
Gladiator’s proprietary VELOX® high-speed processing engine delivers ultra-low latency and multiple output options, ensuring that the sensor data arrives fast and clean — critical for dynamic fire-control, navigation, and robotic guidance loops.
🛰️ Proven in Defense and Autonomous Systems
From armored vehicles to UAV gimbals, the LandMark005 IMU provides a stable reference point that enhances targeting, situational awareness, and control precision.
By compensating for motion in real time, it enables operators and AI algorithms alike to see clearly, aim accurately, and act decisively.
Precision isn’t a luxury – it’s a requirement.
Gladiator Technologies – Precision that powers possibilities.
Amironic – Authorized representative of Gladiator Technologies in Israel.
